DOES NOT INCLUDE FREIGHT AND SET UP
HAS SPLIT BEAM LIGHT INSTALLED
ENGINE
| Engine Name | Kawasaki FR691 |
| Horsepower | 23HP |
| Fuel Capacity | 5gal |
DRIVE LINE
| Hydraulic Drive | Tuff Torq 400 Series |
| Hydraulic Drive Torque | Continuous - 1425in-lb | Max Torque - 3540in-lb |
| Hydro Drive Maintenance | 200 Hours Between Oil Changes (when used in severe duty) |
| Drive Tires | 48", 54" - 22x11-R10 Turf Armor |
| Front Tires | 13x6.5-R6 Smooth Tread |
| Wheels Type | Steel |
| Speed (F/R) | Forward - Up to 8.5mph | Reverse - Up to 5mph |
FEATURES
| Seat | Stylish & Comfortable |
| Steering Levers | Adjustable Up and Down |
| Control Panel LCD Display | Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time between Oil Change Countdown - Fault Codes |
| Control Panel LED Warning Indicators | Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI |
| Ignition | Keyless, Enter Personal Code to Start |
| Auxiliary Power | 12v Outlet |
| Storage | Large Cup Holder & Storage Tray |
| Hitch | N/A |
CUTTING DECK
| Deck Sizes | 48", 54" |
| Deck Depth | 5" Deep, Full-Floating Deck |
| Deck Lift | Foot Operated with Shock Assist |
| Deck Adjustment | Quick Adjust Dial from 1" to 4.25" with 12 Cut Heights |
| Cut Height | 1" to 4.25" with 12 Cut Heights in Between |
| Blade Spindles | Cast Aluminum, No Maintenance/Sealed Double Bearings |
| Parking Brake | Foot Operated |
| Frame | 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame |
MEASUREMENTS
| Width | 48" Deck - 49.5" | 54” Deck - 55.5” Wide |
| Weight | 48" - 782lbs| 54” - 801lbs |
| Length | 81” |
| Height | 46" |
WARRANTY
| Engine Warranty | 3 Years |
| Full Warranty | 3 Year / 300 hour - 120 Day Belt Warranty |
| Deck Warranty | Lifetime on the leading edge. See full warranty for disclosure and restricitons |
| Hydraulic Drive Warranty | 3 Year / 300 Hour |
| Control Panel Warranty | 3 Years |
